Small Waste Paper Horizontal Baler Machine Manufacturer
Need a compact, high-throughput solution for waste paper? Our small waste paper horizontal baler machines combine a space-saving footprint with industrial-grade compression to produce dense, stackable bales that cut storage costs and boost scrap value. Engineered for corrugated boxes, office paper, newspapers, magazines, and packaging trims, these balers are ideal for warehouses, print houses, retail backrooms, logistics hubs, and recycling centers.
Why Choose a Small Horizontal Baler?
Compared to vertical models, a small horizontal baler offers faster cycles, easier continuous feeding, and uniform bale density—without demanding a large plant area. With low energy consumption and simplified controls, your team can bale more in less time, keep aisles clear, and maintain cleaner operations.
Available Configurations
- Manual-Tie Horizontal – Budget-friendly, compact frame. Operators tie bales with PET/steel straps.
- Semi-Automatic Horizontal – Powered bale ejection, PLC controls, recipe presets for paper grades.
- Auto-Tie (Compact) – For higher volumes; continuous feed with automatic strapping to minimize labour.
- Conveyor / Air-Duct Feed Ready – Optional infeed conveyor or trim-collection ducting for print & packaging lines.
Key Features
- High-pressure hydraulic system with heavy-duty cylinders for dense bales.
- Hardened wear plates and replaceable liners in the compression chamber.
- PLC-based controls, HMI with bale counter, alarm logs, and maintenance prompts.
- Adjustable bale size & compression cycles to match paper grade and moisture.
- Interlocks, emergency stops, door switches & overload protection for operator safety.
- Low HP motors with optimized hydraulics for reduced energy consumption.
- Easy access for cleaning, oil filtration ports, and centralized greasing points.
Applications
- Converting OCC, kraft, duplex and mixed paper into compact bales for sale/transport.
- Trim collection from printing & packaging lines with conveyor or air-duct feed.
- Retail & e-commerce warehouses handling daily carton waste and dunnage.
- Corporate offices and institutions processing shredded or sorted office paper.
Benefits
- Higher throughput than vertical balers in a comparable footprint.
- Lower logistics cost via denser, uniform bales and faster truck loading.
- Cleaner floors, safer aisles, and improved housekeeping scores.
- Simple operation, fewer labour hours, and quick operator training.
- Local spares & service support for minimum downtime.
Typical Technical Window (Guidance)
Note: Specs are customizable based on paper grade, bale size, and available space.
- Chamber: ~1000–1200 mm (L) × 600–700 mm (W) × 600–800 mm (H).
- Bale Size: ~700–900 mm (W) × 500–700 mm (H) × variable length.
- Bale Weight: 80–180 kg (paper grade & moisture dependent).
- Throughput: 1–2.5 TPH (with proper feeding and operator efficiency).
- Motor: 7.5–15 HP; Hydraulic pressure tuned for paper grades.
Maintenance Tips
- Inspect strapping path and cutters daily; replace dull knives to avoid mis-ties.
- Keep chamber clean; remove lodged paper from corners to prevent wear.
- Monitor hydraulic oil level & temperature; change filters at recommended intervals.
- Check cylinder seals and hose joints for leaks; tighten fittings proactively.
- Calibrate bale length sensor/encoder periodically for consistent bale sizes.
FAQs – Small Waste Paper Horizontal Baler
1. How do I select the right baler capacity?
+
Match expected hourly paper volume and desired bale weight. Share OCC/mixed paper ratio, floor space, and feeding method for a precise model.
2. Can I integrate a conveyor or trim ducting later?
+
Yes. Frames can be provisioned for conveyor or air-duct infeed so you can start manual and upgrade as volumes grow.
3. What bale tying options are available?
+
PET or steel strapping, manual-tie, semi-auto ejection, or compact auto-tie—chosen by throughput and labour availability.
4. What about power consumption?
+
Small horizontal balers typically run 7.5–15 HP motors with optimized hydraulic circuits to minimize kWh per tonne baled.
5. Do you offer AMC and operator training?
+
Yes—installation, on-site training, spares support, and annual maintenance contracts are available across India.
